LRS801GKA604A1

Width / Cutting: Deck 60"

Drive: UHT Hydro-Drive

Starter: Electric

Steering Control: Hydraulically dampened twin levers adjustable both fore and aft. Also has 2-position height adjustment. Adjustable dampers (3 positions) to customize drive responsiveness

Caster Forks: .50" thick caster yoke arms.

Front Caster Tires: 13 x 6.5-6, smooth tread, semi-pneumatic

Drive Tires: 24 x 12-12, 4 ply Grass Master TL

Parking Brake: Lever actuated disc brake

Tractor Frame:  Unibody, welded, heavy-duty 1.5" x 3" tubular steel.

Blade Spindles: No maintenance, sealed and non-greaseable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft and splined blade driver.

Electrical: 12-volt battery with 15-amp alternator.

Standard Features: Engine hour meter and cup holder

Transmission Speeds: Infinitely Variable

Engine Brand: Kawasaki®

Engine Model: FX801V

Engine Displacement:  852

Speed: Infinitely variable speed selection from 0–10.0 mph forward, 0–7.0 mph reverse

Fuel Capacity: 12-gallon single fuel tank with single fill location

Drive Description:  Two Exmark exclusive Parker unitized pump and wheel motor systems with no hoses, integrated cooling fans, 1.7-quart integrated reservoir, spin-on filter and heavy-duty components. 12 cc pumps and 14. 5 cubic inch motors.

PTO Engagement: MagStop electromagnetic 200-ft-lb clutch with spot brake

Deck Construction: 10-gauge top that is formed and continuously seam welded, 7-gauge side skirt and 7-gauge formed and welded spindle mounting locations for improved strength and reduced weight.

Cutting Heights: 1.0" to 5.5" in 0.25" increments

Blade Tip Speed: Approximately 18,500 fpm
